GL McGavin Modiewark HV Proximity Tester Model CIG

GL McGavin’s Modiewark High Voltage Proximity Tester is the original AC non-contact Voltage Tester. Detects voltage without touching the voltage source and informs the operator audibly and visually. Multiple models to detect voltages in a variety of ranges to suit your on-site requirements.

Key Features:

Frequently purchased models:
CIG – Selectable Voltages:� OFF, 240V, 415kV, 3.3kV, 6.6kV, 11kV, 22kV, 33kV, 66kV
S7 – Selectable Voltages: OFF, 240V, 2kV, 11kV, 22kV, 33kV, 66kV
S9 – Selectable Voltages: OFF, 240v, 2kV, 11kV, 22kV, 33kV, 66kV, 132kV, 330kV
SEAQ – Selectable Voltages: OFF, 240V, 3.3kV, 6.6kV, 11kV, 33kV, 66kV, 110kV, 275kV
MWB – Selectable Voltages: OFF, 240V, 3.3kV, 6.6kV, 11kV, 22kV, 33kV
Other models and options are located within the More Information tab.
If you require a Custom product, or other models not listed on the website please enter the relevant information in the cart checkout page under ‘Order Notes’.
Size: 23cm x 10cm x 10cm
Colour: Orange
Weight: 900g
Operating Temperature: -10C – 65C
Suitable to combine with most insulated sticks
Multiple models to detect different voltage ranges
Comes with 3 x C batteries to ensure on-site readiness
Self test function to verify tester is working appropriately
Easy selection wheel to change voltage source detection value
Loud 85dB buzzer sound to allow for audible detection of voltage source
Bright red detection light allows for visual detection of voltage source in noisy environments
Identification of the voltage source detection values from 200mm – 300mm away from the voltage source

Standards:

IP63

Options:

Modiewark High Voltage Proximity Tester Electrical Safety Kit – G.L McGavin
An Electrical Safety Kit that includes Insulated Sticks, Insulated stick attachments, a Modiewark and a Modiewark tester
